Price
$349.99
Taxes and shipping calculated at checkout

Stock Notification

Get notified when this product is available again

Frequently Bought Together

Have a question?

Mackie Big Knob Studio+ 4x3 Studio Monitor Controller and Interface

Big Knob Series Monitor Controllers & Interfaces

Always
In Touch

Studios of any size can benefit from the professional source/monitor selection and precise level control of the Big Knob Series. Plus, with the addition of high-resolution Onyx™ USB recording and playback, studios get a powerful, hybrid solution that is truly greater than the sum of its parts.

More

Than meets the eye

Sure, we all know the Mackie Big Knob is the go-to monitor controller for studios the world over. But, now that we've added in the high-resolution goodness of an Onyx recording and playback solution, Big Knob truly becomes the nerve center for your studio. Or, if you are looking for excruciatingly simple volume control/monitor switching, the Big Knob Passive delivers at an amazing price. No matter what size studio, Big Knob is always at the top of the recording studio equipment shopping list.

Mackie Big Knob Studio+ Monitor Controller/USB Audio Interface Features:

  • Studio monitor controller and USB audio interface
  • Dual Onyx preamps for recording high-fidelity, low-noise audio
  • Easily switch between four input sources and three monitor pairs
  • Trim controls allow you to balance the volume of different pairs of monitors
  • Talkback for communicating with artists
  • Headphone outputs for artist monitoring
  • Stereo aux input for connecting music player for reference tracks
  • Large volume knob for easy level adjustments
  • Handy buttons for Mono, Mute, and Dim
  • Dedicated amp-driven Studio Out for headphone distribution systems

Mackie Big Knob Specs

Inputs 2 x Combo XLR-1/4" TRS Balanced/Unbalanced Mic/Line Inputs
4 x 1/4" TRS Balanced/Unbalanced Line Inputs
2 x 1/4" TRS Balanced/Unbalanced Cue Input
1 x 1/8" / 3.5 mm TRS Unbalanced Stereo Input
1 x 3-Pin XLR Talkback Mic Input
Outputs 2 x 1/4" TRS Balanced/Unbalanced 2-Track Line Outputs
6 x 1/4" TRS Balanced/Unbalanced Monitor Outputs
2 x 1/4" TRS Balanced/Unbalanced Monitor/Line Outputs
2 x 1/4" TRS Unbalanced Headphone Outputs
Footswitch Input 1 x 1/4" TRS
USB I/O 1 x USB 2.0 Type-B
Resolution 24-Bit / 192 kHz
Frequency Response 20 Hz to 20 kHz (±0.5 dB, Unity Gain, +4 dBu Input)
Noise Mic Inputs to Outputs: < -125 dBu RMS, A-Weighted (150 Ohms Terminated, 22 kHz Bandwidth)
Line Inputs to Outputs: < -90 dBu RMS, Unweighted (150 Ohms Terminated, 22 kHz Bandwidth)
THD + N <0.01% Unweighted (Unity Gain, 1 kHz at +4 dBu Input, 80 kHz Bandwidth)
Crosstalk < -60 dB at 1 kHz (Unity Gain, -1 dBFS Input)
Attenuation Muted: -60 dB
Dim: -20 dB
Maximum Input Level +22 dBu
Maximum Output Level +22 dBu
Power Requirements 100 to 240 VAC, 50/60 Hz, 0.75 A via Universal Power Supply
Dimensions (W x D x H) 6.8 x 11.9 x 3.2" / 17.3 x 30.2 x 8.1 cm
Weight 4.6 lb / 2.1 kg
Packaging Info
Package Weight 6.545 lb
Box Dimensions (LxWxH) 15.4 x 9.55 x 5.65"
