Adam Audio ADAM Sub12

The Sub12 is a powerful subwoofer designed to extend the low frequency capabilities of any near or midfield monitoring system down to 22 Hz.

A sturdy special woofer with extended cone travel and a heavy-duty coil have been optimized for accurate reproduction from a bass reflex enclosure. The down-firing bass reflex tube avoids intrusive ventilation noise because of its generous size and shape. The PWM amplifier produces over 90% efficiency and can handle critical passages without overheating for long periods of time. An additional output allows you to cascade as many subwoofers as needed.

The Sub12 subwoofer provides a precise combination of low cutoff frequency (-3dB at 22Hz) and an undistorted high sound pressure level (115dB SPL at 1m).

Features & Benefits

  • Bass reproduction down to 22 Hz
  • Ideal addition to nearfield and midfield monitors
  • Maximum Peak sound pressure in 1 m ≥ 115 dB
  • Powerful, compression-free sound reproduction even at very high sound levels
  • High efficiency PWM amplifier
  • Low-distortion amplification at both low and high volume levels
  • Special 12" woofer with paper diaphragm
  • Unrestricted bass reproduction for low-fatigue operation even at high volumes
  • Easy manual or automatic (de-)activation
  • If desired, monitoring is possible without the low frequencies
  • Additional sub output
  • Allows building a (double) bass array
  • According to downward working bass reflex tube with generous dimensions and corresponding rounding
  • Prevention of air turbulence noise
  • Crossover frequency is selectable between 50 - 150 Hz
  • Allows optimal adaptation of the total system on the bass performance of the satellites
  • Connectable high-pass filter for the satellite outputs, which blocks signals below 85 Hz
  • Dolby®- Fair reproduction of film sound
  • Discharging the satellites from the low frequencies
  • 2 years warranty with optional extension to 3 years with the registration of the product
  • Full repair service if required for 5 years

 Technical Data

  • Subwoofer
  • Number    1
  • Basket Ø    12" (310 mm)
  • Voice Coil Ø    2" (50 mm)
  • Cone Material    Paper
  • Built-in Amplifiers
  • Subwoofer    1
  • Type    PWM
  • Amp. Power RMS / Music    200 W / 300 W
  • Input Connectors
  • Analog    XLR / RCA
  • General Data
  • Frequency Response    22 Hz - 150 Hz
  • THD > 60 Hz    ≤1 %
  • Max. peak SPL at 1 m    ≥115 dB
  • Crossover Frequencies    50 - 150 Hz
  • Input Impedance    10 kOhm
  • Panel    Rear
  • Weight    57.3 lb (26 kg)
  • Height x Width x Depth    23.5" (600 mm) x 14" (360 mm) x 17.5" (450 mm)
  • Warranty    5 years (2 years warranty plus 3 years optional with product registration)
  • Delivery contents    Power cord, manual
