Apogee Element 46 - 12x14 Thunderbolt Audio Interface for Mac

Product Description
$895.00

The Elements of Excellent Audio

Analog to Digital Conversion

A high-quality A/D converter is critical for capturing every detail of your recordings into your computer. The Element series features some of the best Apogee A/D conversion. Recording through an Element ensures you will minimize unwanted noise and maximize the signal quality. Your tracks will sound amazing and mixing your project will be easier.

Microphone Preamps

Whether you are recording powerful drums, dynamic vocals or delicate strings, you need a premium mic preamp to capture the finest details of the performance. The Element Series mic preamps feature Apogee’s Advanced Stepped Gain Architecture™. This analog circuit is designed to dynamically optimize across a gain range of 0-75dB to provide superior bandwidth and low distortion.

Digital to Analog Conversion

With a high-quality D/A converter, you will hear more definition in each track and virtual instrument. This clarity makes it easier for you to make precise adjustments and achieve the ideal balance when mixing your music. When you listen to your sessions through an Element, tracks will blend more harmoniously and mixing will be easier. The high end will sound crisp and clear and the low end will be tight and well defined.

Clocking

An audio interface relies on a clock source like an orchestra relies on a conductor. A digital audio clock provides a timing signal to all the parts of a digital audio system so that each part of the AD/DA process may be synchronized. Element has its own built-in clock source and provides professional Word Clock IN and OUT for syncing with other digital audio gear. Use Element as the master clock to take advantage of Apogee’s superior built-in clocking technology.

Thunderbolt Connectivity

The Element Series Thunderbolt driver offers incredible low-latency performance (1.41 ms round-trip) and rock-solid stability. Apogee’s custom driver uses less of your computer’s CPU power with the help of Direct Memory Access (DMA) technology. This allows you to run more plugins and monitor through your DAW at a low buffer setting. Element’s low latency driver means you don’t have to choose between power and speed.

Highlights

  • 12 IN x 14 OUT Audio I/O box
  • AD/DA conversion for recording up to 192kHz/24-bit
  • 4 analog inputs with world-class mic preamps and selectable 48v phantom power for connecting microphones, instruments or line-level devices
    • 4 combination inputs
  • 6 analog outputs
    • 2 balanced L/R XLR outputs
    • 2 1/4” stereo headphone output
  • Single port Thunderbolt connectivity to Mac for ultra-low latency performance
    • 1.41ms round-trip at 96kHz with a 32 buffer setting
  • Optical IN: Supports ADAT, SMUX & S/PDIF
    • ADAT: 8 channels 44.1-48 kHz on 1 Toslink connector
    • SMUX: 4 channels 88.2-96 kHz on 1 Toslink connector
    • S/PDIF: 2 channels, up to 192 kHz on 1 Toslink connector

Specifications:

Element 46 Highlights

  • 12 IN x 14 OUT Thunderbolt Audio I/O box
  • AD/DA conversion for recording up to 192kHz/24-bit
  • 4 analog inputs with world-class mic preamps and selectable 48v phantom power for connecting microphones, instruments or line-level devices
    • 4 combination inputs
  • 6 analog outputs
    • 2 balanced L/R XLR outputs
    • 2 1/4” stereo headphone output
  • Single port Thunderbolt connectivity to Mac for ultra-low latency performance
    • 1.41ms round-trip at 96kHz with a 32 buffer setting
  • Optical IN: Supports ADAT, SMUX & S/PDIF
    • ADAT: 8 channels 44.1-48 kHz on 1 Toslink connector
    • SMUX: 4 channels 88.2-96 kHz on 1 Toslink connector
    • S/PDIF: 2 channels, up to 192 kHz on 1 Toslink connector
  • Optical OUT: Supports ADAT, SMUX & S/PDIF
    • ADAT: 8 channels 44.1-48 kHz on 1 Toslink connector
    • SMUX: 4 channels 88.2-96 kHz on 1 Toslink connector
    • S/PDIF: 2 channels, up to 192 kHz on 1 Toslink connector
  • Word Clock IN/OUT via BNC connections for syncing with other digital audio gear
  • Element Control Software for Mac provides all control of hardware parameters including input gain, output level and low latency monitoring
  • Element Control Mobile App provides wireless remote control of hardware via iPhone, iPad or iPod touch
  • Works with Apogee Control – Optional desktop hardware remote control (Sold separately)
  • Multi-Unit Thunderbolt support – Connect any two Element audio I/O boxes directly to Thunderbolt ports on your computer

Weights and Dimensions

  • 11.5” x 5.5” x 1.75″
  • 29.5cm x 14cm x 4.5cm
  • 2.95lbs
  • 1.34kg

System Requirements

Mac OS:

  • Computer: Thunderbolt-equipped Mac (iMac, Macbook Pro, Macbook Air, Mac Pro)
  • Memory: 4 GB RAM minimum, 8 GB recommended
  • OS: 10.10 or greater
  • Connection: Any available Thunderbolt port*
  • Power: DC Power supply included

*Thunderbolt cable not included

Compatible Software:

  • Any Mac Core Audio compatible application
  • Recommended apps: Logic Pro, Pro Tools, Ableton Live, GarageBand, MainStage, Final Cut, Digital Performer, Studio One, Cubase, and Nuendo

In the box:

  • Element 46
  • Universal Power Supply with standard 3 pin-IEC cable
  • Quick Start Guide
  • Warranty Booklet

Mic Preamps:

  • 4 Mic preamps
  • Gain: Up to 75 dB and advanced stepped gain circuit design
  • Selectable 48v phantom power, Soft Limit and polarity invert
  • EIN: 129dB (un-weighted) @ 60dB, 150Ohm input
  • Max input level: +20dBu
  • Input impedance: 3K Ohm

A/D conversion:

  • Max input level (+4dBu ref/Mic): +20dBu
  • Max input level (-10dBV ref): +6dBV
  • Input impedance: 5KOhm
  • Freq resp 10 Hz -20Khz: > +/-0.2dB (@44.1Khz)
  • Rel. THD + N: -110dB
  • Dyn. Range: 119dB (A-weighted)

D/A conversion:

  • Max output level (+4dBu ref): +20dBu
  • Max output level (-10dBV ref): +6dBV
  • Line output impedance: 90 Ohm
  • Freq resp 10Hz -20 Khz: > +/- 0.05dB (@44.1Khz)
  • Rel. THD+N : -114dB
  • Dyn Range: 123dB (A-weighted)
  • Headphone Max output level:
    • 560mW into 30 Ohm
    • 90mW into 600 Ohm
  • Headphone THD+N: -107 dB with 600 Ohm load @ 19 dBu
  • Headphone Dyn Range: 117dB a-weighted
