Audient iD44

Product Description
$509.00
Maximum quantity available reached.
Audient iD44

For the Creatives
20in/24out Audio Interface

iD44 features four Class-A console mic pres, the same discrete circuit design found in our renowned recording console the ASP8024-HE and throughout our product range. Designed to deliver ultra- low noise and low distortion, the Audient mic pre will provide an accurate reproduction of your source, along with enough analogue warmth to add a bit of character, making it the go to mic pre for any project.

Features
  •     20-in, 24-out Desktop Interface
  •     4 x Class-A Audient Console Mic Preamplifiers
  •     Class Leading AD/DA Converters
  •     2 x ADAT Inputs & Outputs for Digital Expansion
  •     2 x Discrete JFET Instrument Inputs
  •     2 x Fully Balanced Inserts
  •     2 x Independent Stereo Headphone Outputs
  •     Main and Alt Speaker Outputs
  •     ScrollControl
  •     3 x User Defined Function Keys
  •     Dedicated Talkback, Dim and Cut Controls
  •     Power Switch
  •     Low Latency DSP Mixer
  •     Word Clock Output
  •     USB2.0 Compliant
  •     24bit/96khz
  •     All-Metal Enclosure & hand-milled aluminium knobs
  •     Over £500 worth of plugins and software free with ARC
Specifications

MICROPHONE PREAMPLIFIER:
(measured to insert send)
MIC GAIN:     0 to +60 dB
LINE GAIN:     -10 to +50 dB
PHANTOM POWER:     48v +/-4v @ 10mA/Channel
MIC EIN:     <-126dBu
CMRR:     >80dB @ 1kHz
MAXIMUM INPUT LEVEL:     +18dBu (+28dBu with pad)
INPUT IMPEDANCE (Mic):     >3kΩ Balanced
INPUT IMPEDANCE (Line):     >10kΩ Balanced
FREQUENCY RESPONSE:     +/-0.5dB 10Hz to 65kHz
CROSSTALK:     <-90dBu @ 1kHz & 10kHz
THD+N @ 0dBu (1kHz):     0.003% (-96dBu)
SNR:     96dB
Pad:     -10dB
HPF:     -3dB @ 100Hz, 2nd Order (12dB/Octave)
XLR:     Pin 2 (Hot), Pin 3 (Cold) & Pin 1 (Shield)
1/4” JACK:     TIP (Hot), RING (Cold) & SLEEVE (Shield)
D.I (Channel 1):

(measured to insert send)
D.I GAIN:     -0 to +60 dB
MAXIMUM INPUT LEVEL:     +10dBu
INPUT IMPEDANCE:     1MegΩ Unbalanced
FREQUENCY RESPONSE:     +/-0.5dB 10Hz to 50kHz
THD+N @ 0dBu (1kHz):     <0.3%
SNR:     95dB
1/4” JACK:     TIP (Hot) & SLEEVE (Shield)
INSERT SENDS (Mic Pre Out):
MAXIMUM OUTPUT LEVEL:     +18dBu
OUTPUT IMPEDANCE:     <100Ω Balanced
1/4” JACK:     TIP (Hot), RING (Cold) & SLEEVE (Shield)
ADC LINE INPUTS (Insert Returns):

(measured at optical output under AES-17)
MAXIMUM INPUT LEVEL:     +18dBu
DIGITAL REFERENCE LEVEL:     0dBFS = +18dBu
INPUT IMPEDANCE:     >10kΩ Balanced
FREQUENCY RESPONSE:     +/-0.5dB 10Hz to Fs/2
CROSSTALK:     -115dBu @ 1kHz & 10kHz
THD+N @ -1dBFS (1kHz):     <0.0008% (-103dB)
DYNAMIC RANGE:     121dB A-weighted
1/4” JACK:     TIP (Hot), RING (Cold) & SLEEVE (Shield)
DAC OUTPUTS (1-4):

(measured from optical input under AES-17)
MAXIMUM OUTPUT LEVEL:     +18dBu
DIGITAL REFERENCE LEVEL:     0dBFS = +18dBu
OUTPUT IMPEDANCE:     <100Ω Balanced
FREQUENCY RESPONSE:     +/-0.5dB 10Hz to Fs/2
CROSSTALK:     -118dBu @ 1kHz & 10kHz
THD+N @ -1dBFS (1kHz):     <0.0006% (-104dB)
DYNAMIC RANGE:     126dB A-weighted
1/4” JACK:     TIP (Hot), RING (Cold) & SLEEVE (Shield)
HEADPHONE OUTPUT (5&6):

(measured from optical input under AES-17)
MAXIMUM OUTPUT LEVEL:     +14dBu
DIGITAL REFERENCE LEVEL:     0dBFS = +14dBu
OUTPUT IMPEDANCE:     <50Ω Balanced
FREQUENCY RESPONSE:     +/-0.5dB 10Hz to Fs/2
CROSSTALK:     -110dBu @ 1kHz & 10kHz
THD+N @ -1dBFS (1kHz):     <0.0008% (-103dB)
DYNAMIC RANGE:     124dB A-weighted
MAX LEVEL INTO 30hms:     +7.5dBu, 0.003%
THD+N, 2.6Vpk
Power: 225mW or Pavg 112.6mW
MAX LEVEL INTO 6ohms:     +10.2dBu, 0.002%
THD+N, 3.55Vpk
Power: 210mW or Pavg 105mW
MAX LEVEL INTO 600ohms:     +14.2dBu, 0.001%
THD+N, 5.7Vpk
Power: 54mW or Pavg 27mW
1/4” JACK:     TIP (Hot), RING (Cold) & SLEEVE (Shield)
DIGITAL i/o:
ADAT 16 CHANNELS     44.1 - 48kHz
ADAT 8 CHANNELS (SMUX)     88.2 - 96kHZ
STEREO S/PDIF     44.1 - 96kHz
USB2.0 HIGH SPEED
No. of INPUT CHANNELS 20     (4 Analogue, 16 Digital)
No. of OUTPUT CHANNELS 24     (8 Analogue, 16 Digital)
Connector:     USB Type-C
Included Cables:     1.5m USB 2.0 Type-C to USB Type-C
1.5m USB 2.0 Type-C to USB Type-A
iD DSP Mixer Roundtrip (in to out) Latency:
44.1 kHz     0.677ms
48.0 kHz     0.625ms
88.2 kHz     0.345ms
96.0 kHz     0.3236ms
DAW Playback Latency @ 32 Sample Buffer for Software Instrument Playback:
44.1 kHz     ~2.5ms
96.0 kHz     ~1.6ms
DAW Roundtrip Software Monitoring Latency @ 32 Sample Buffer (in to out):
44.1 kHz     5.6ms
96.0 kHz     4.2ms
POWER SUPPLY:



12VDC Centre Positive DC Adapter - 2Amps
Internally conditioned to provide +48VDC, +/-15VDC & low voltage rails for digital processing core & converters. iD44 cannot be bus powered for quality reasons.

Weight:
Unit: 1.75kg

Packaged: 2.4kg

Dimensions:
Unit: 276mm (w) x 51mm (h) x 174mm (d)
Packaged: 354mm (w) x 103mm (h) x 229mm (d)




Sku:
Vendor: Audient
