Audient Sono

Audient Sono

Guitar Recording Interface
The Ultimate Valve Guitar Preamp
Dial Up Tones Instantly

Combining an on board 12AX7 analogue valve and 3-band Tone control with Two notes Torpedo power amp modelling and cab simulation, Sono lets you quickly create, record and store the guitar sounds you hear in your head.

Onboard DSP
Two notes Torpedo Remote Software
We teamed up with Two notes to bring you their renowned Torpedo Power Amp Modelling and Cab Simulation built straight into Sono.  Letting you accurately emulate the sound and process of miking a guitar or bass cabinet in a professional recording studio all from your desktop.
Record through
your favourite cabs

Pick and choose from a wide range of guitar and bass cabs models and play through or record classics such as the Marshall 4x12, Fender 2x12, Ampeg 8x10 and many more.

Features

• 10 in/4 out USB interface
• Classic Valve Preamp with 12AX7 Valve
• 3 Band Tone Control
• Two notes Power Amp and Cab Simulation
• Re-amp Output
• 2x Audient Console Mic Pres
• High Performance AKM AD/DA Converters
• ADAT Input for Expandability
• Main Speaker Output
• Independent Headphone Output
• Zero Latency Monitoring with Monitor Mix
• USB2.0 Compliant
• 24bit/96khz
• All-Metal Enclosure
• Free plugins and software with ARC

Specifications
MICROPHONE PREAMPLIFIER:

(measured to insert send)
MIC GAIN:     0 to +60 dB
LINE GAIN:     -10 to +50 dB
PHANTOM POWER:     48v +/-4v @ 10mA/Channel
MIC EIN:     -128dBu
CMRR:     >80dB @ 1kHz
MAXIMUM INPUT LEVEL:     +16dBu
INPUT IMPEDANCE (Mic):     >3kΩ Balanced
INPUT IMPEDANCE (Line):     >10kΩ Balanced
FREQUENCY RESPONSE:     +/-0.5dB 10Hz to 22kHz
CROSSTALK:     <-90dB @ 1kHz & 10kHz
THD+N @ 0dBu (1kHz):     0.003% (-96dBu)
SNR:     96dB
XLR:     Pin 2 (Hot), Pin 3 (Cold) & Pin 1 (Shield)
1/4” JACK:     TIP (Hot), RING (Cold) & SLEEVE (Shield)
D.I (Channel 1):
D.I GAIN:     20 dB
MAXIMUM INPUT LEVEL:     +4dBu
INPUT IMPEDANCE:     1MegΩ Unbalanced
FREQUENCY RESPONSE:     ±3dB - 10Hz to 22kHz
THD+N @ 0dBu (1kHz):     1.50%
SNR:     90dB
1/4” JACK:     TIP (Hot) & SLEEVE (Shield)
ADC INPUTS:
MAXIMUM INPUT LEVEL:     16dBu
DIGITAL REFERENCE LEVEL:     0dBFS = +16dBu
FREQUENCY RESPONSE:     +/-0.5dB 10Hz to Fs/2
CROSSTALK:     <-115dB @ 1kHz & 10kHz
THD+N @ -1dBFS (1kHz):     <0.0015%
DYNAMIC RANGE:     115dB A-weighted
1/4” JACK:     TIP (Hot), RING (Cold) & SLEEVE (Shield)
SPEAKER OUTPUTS:
MAXIMUM OUTPUT LEVEL:     +16dBu
DIGITAL REFERENCE LEVEL:     0dBFS = +16dBu
OUTPUT IMPEDANCE:     <100Ω Balanced
FREQUENCY RESPONSE:     +/-0.5dB 10Hz to Fs/2
CROSSTALK:     <-120dB @ 1kHz & 10kHz
THD+N @ -1dBFS (1kHz):     <0.0015%
DYNAMIC RANGE:     114dB A-weighted
1/4” JACK:     TIP (Hot), RING (Cold) & SLEEVE (Shield)
HEADPHONE OUTPUT:
MAXIMUM OUTPUT LEVEL:     +16dBu
DIGITAL REFERENCE LEVEL:     0dBFS = +16dBu
OUTPUT IMPEDANCE:     <50Ω Balanced
FREQUENCY RESPONSE:     +/-0.5dB 10Hz to Fs/2
CROSSTALK:     -90dB @ 1kHz & 10kHz
THD+N @ -1dBFS (1kHz):     <0.002%
DYNAMIC RANGE:     114dB A-weighted
MAX LEVEL INTO 30hms:     +10dBu, 0.0015%
THD+N, 3.7Vpk
Power: 456mW or Pavg 228mW
MAX LEVEL INTO 6ohms:     +13.5dBu, 0.0015%
THD+N, 5.17Vpk
Power: 445mW or Pavg 222mW
MAX LEVEL INTO 600ohms:     +15.8dBu, 0.0015%
THD+N, 6.77Vpk
Power: 76mW or Pavg 38mW
1/4” JACK:     TIP (Hot), RING (Cold) & SLEEVE (Shield)
TO-AMP OUTPUT:
MAXIMUM OUTPUT LEVEL:     -12dBu
DIGITAL REFERENCE LEVEL:     0dBFS = -12dBu
OUTPUT IMPEDANCE:     <50Ω Balanced
FREQUENCY RESPONSE:     +/-0.5dB 10Hz to Fs/2
THD+N @ -1dBFS (1kHz):     <0.002%
DYNAMIC RANGE:     95dB A-weighted
1/4” JACK:     TIP (Hot) and SLEEVE (Shield)
DIGITAL i/o:
ADAT 8 CHANNELS     44.1 - 48kHz
ADAT 4 CHANNELS (SMUX)     88.2 - 96kHZ
STEREO S/PDIF     44.1 - 96kHz
USB2.0 HIGH SPEED
No. of INPUT CHANNELS 20     10 (2 Analogue, 8 Digital)
No. of OUTPUT CHANNELS 24     4 (4 Analogue)
Connector:     USB Type-C
Included Cables:     1.5m USB 2.0 Type-C to USB Type-C
1.5m USB 2.0 Type-C to USB Type-A
Sono DSP Mixer Roundtrip (in to out) Latency:
      Without Torpedo Processing     With Torpedo Processing
44.1 kHz     0.677ms     4.63
48.0 kHz     0.625ms     4.18
88.2 kHz     0.354ms     3.26
96.0 kHz     0.3236ms     2.99

POWER SUPPLY:
12VDC Centre Positive DC Adapter - 2Amps
Internally conditioned to provide +48VDC, +/-12VDC & low voltage rails for digital processing core & converters.
Sono cannot be bus powered for quality reasons.

Weight:
Unit: 1.25kg

Packaged: 2.0kg

Dimensions:
Unit: 229mm (w) x 67mm (h) x 165mm (d)

Packaged: 315mm (w) x 112mm (h) x 226mm (d)
